Triple Effect Evaporator

  •  Triple Effect Evaporator
  •  Triple Effect Evaporator

Applications
The triple effect evaporator uses a tubular circulation heating principle to shorten heating time for rapid evaporation and large concentration ratio, so as to maintain the properties of the raw materials.

Parameters
Model/items Drying capacity Heat exchanging area (m2) Condensing area(m2) Evaporating temperature(℃) Vacuum degree(MPa) Dimension
H2O(kg/h) Primary efficiency evaporator Medium efficiency evaporator High efficiency evaporator Primary efficiency evaporator Medium efficiency evaporator High efficiency evaporator (L×W×H)
SZ-500 500 15 7.5 85 75 60 0.02 0.06 0.08 5.9×1.25×2.49
SZ-1000 1000 30 15 85 75 60 0.02 0.06 0.08 6.8×1.45×3.5
SZ-2000 2000 60 30 85 75 60 0.02 0.06 0.08 9.3×1.8×4.2

Features
This concentrator is suitable for the concentration of liquid materials such as Chinese herbal medicine, western medicine, glucose, starch, foodstuffs, dairy products and chemical products. It is especially suitable for thermosensitive materials.
