QG Series Hot Air Dryer

 QG Series Hot Air Dryer

The QG series of hot air dryer is equipped with a fan that is used to disperse material to crush wet and blocked raw material that is heat sensitive. It is applicable for drying raw materials that have surface moisture less than 40%. If the amount of material being dried is large or the moisture required for the finished products is less than 60%, two grades of drying can be used. Drying efficiency can be greatly increased by adding a centrifugal dryer or roller press prior to the hot air dryer.

Parameters
Model Drying capacity (kg/h) Power (kw) Floor space (m2) Height (m)
QG50 50 7 20 14
QG100 100 13 32 14
QG200* 200 21 40 15
QG250 250 24 64 15
QG500 500 43 96 18
QG1000* 1000 100 120 18
QG1500* 1500 150 200 20
Basic air dryer

1. Air filter
2. Air heater
3. Adjustable feeder
4. Cyclone separator
5. Exhaust fan
6. Dry pipe
